Operating Range:

1.0' - 20.0' (0.30m - 6.0m)

Output:

Selectable: 0-20mA or 4-20mA

Supply Voltage:

12 - 30 V DC

Total Current:

100mA max @ 24 V DC

Housing:

PVC

Transducer Type:

Ceramic, PVC Faced

Ratings:

NEMA 4X, IP65

Response Time:

Programmable

Resolution:

10 bits over the analog span

Accuracy:

0.25% of range with no temperature gradient.

Adjustment(s):

RS-232 Computer Interface

Operating Temp:

-30° to 60° C

Temperature Comp:

Internal

Sample Rate:

Programmable (80m-Sec - 1000m-Sec)

Beam Pattern:

9° off axis

Cable:

9 Conductor 22 AWG PVC Jacket, 6' (1.8m)

Dimensions:

3" diameter x 6.75"
